Storch - GPU Accelerated
Deep Learning for Scala 3

Sören Brunk

USU AI Services

AI is Mainstream

AI is software - just programmed differently

AI needs software

D. Sculley et al.: Hidden Technical Debt in Machine Learning Systems


App A
Business logic
UI
Persistence
Auth
…


App B
Business Logic
UI
Persistence
Auth
…


App C
Business Logic
UI
Persistence
Auth
…

There’s a gap though


App A
Business logic
UI
Persistence
Auth
…


App B
Business Logic
UI
Persistence
Auth
…


App C
Business Logic
UI
Persistence
Auth
…

Storch - a Scala API for PyTorch

Storch

import torch.*
import torch.nn.functional as F


class LeNet[D <: BFloat16 | Float32: Default]
extends nn.Module:
  val conv1 = register(nn.Conv2d(1, 6, 5))
  val conv2 = register(nn.Conv2d(6, 16, 5))
  val fc1 = register(nn.Linear(16 * 4 * 4, 120))
  val fc2 = register(nn.Linear(120, 84))
  val fc3 = register(nn.Linear(84, 10))


  def apply(i: Tensor[D]): Tensor[D] =
    var x = F.maxPool2d(F.relu(conv1(i)), (2, 2))
    x = F.maxPool2d(F.relu(conv2(x)), 2)
    x = x.view(-1, 16 * 4 * 4)
    x = F.relu(fc1(x))
    x = F.relu(fc2(x))
    x = fc3(x)
    x

PyTorch

import torch
import torch.nn as nn
import torch.nn.functional as F

class LeNet(nn.Module):
    def __init__(self):
        super(LeNet, self).__init__()
        self.conv1 = nn.Conv2d(1, 6, 5)
        self.conv2 = nn.Conv2d(6, 16, 5)
        self.fc1 = nn.Linear(16 * 4 * 4, 120)
        self.fc2 = nn.Linear(120, 84)
        self.fc3 = nn.Linear(84, 10)

    def forward(self, x):
        x = F.max_pool2d(F.relu(self.conv1(x)), (2, 2))
        x = F.max_pool2d(F.relu(self.conv2(x)), 2)
        x = x.view(-1, 16 * 4 * 4)
        x = F.relu(self.fc1(x))
        x = F.relu(self.fc2(x))
        x = self.fc3(x)
        return x

Let’s train a model!

Cat

Dog

Cat

Demo

./ImageClassifier train \
  --dataset-dir cats-vs-dogs-sample \
  --base-model ResNet34

Storch Features

Storch aims to offer the same core features as PyTorch:

GPU accelerated tensor operations
Automatic differentiation
A neural network API for building and training machine learning models

Tensors

Tensors are homogeneous multidimensional rectangular arrays of numbers

Creating Tensors

From numbers

torch.Tensor(1)

res3: Tensor[Int32] = tensor dtype=int32, shape=[], device=CPU
1

torch.Tensor(0.5f)

res4: Tensor[Float32] = tensor dtype=float32, shape=[], device=CPU
0.5000

From sequences

torch.Tensor(Seq(true, false, true))

res5: Tensor[Bool] = tensor dtype=bool, shape=[3], device=CPU
[true, false, true]

torch.Tensor(Seq(Seq(1, 2, 3), Seq(4, 5, 6)))

res6: Tensor[Int32] = tensor dtype=int32, shape=[2, 3], device=CPU
[[1, 2, 3],
 [4, 5, 6]]

Creating Tensors

From images (via the Scrimage library)

import torchvision.transforms.functional.toTensor
import com.sksamuel.scrimage.ImmutableImage

val image = ImmutableImage.loader().fromFile("img/cat1.jpg")
val imageTensor = toTensor(image)

image: ImmutableImage = Image [width=325, height=291, type=5]
imageTensor: Tensor[Float32] = tensor dtype=float32, shape=[3, 291, 325], device=CPU
[[[1.0000, 1.0000, 0.9961, ..., 0.9961, 1.0000, 1.0000],
  [0.9922, 0.9843, 0.9961, ..., 1.0000, 0.9961, 1.0000],
  [0.9961, 0.9961, 0.8941, ..., 0.8471, 0.9647, 0.9922],
  ...,
  [1.0000, 1.0000, 0.7216, ..., 0.5020, 0.8431, 0.9961],
  [1.0000, 0.9882, 0.6000, ..., 0.5255, 0.8431, 1.0000],
  [1.0000, 1.0000, 0.9961, ..., 0.9843, 1.0000, 0.9882]],
 [[1.0000, 1.0000, 1.0000, ..., 0.9882, 0.9961, 0.9961],
  [0.9922, 0.9922, 1.0000, ..., 1.0000, 0.9882, 0.9922],
  [1.0000, 1.0000, 0.8980, ..., 0.8431, 0.9608, 0.9843],
  ...,
  [0.9922, 1.0000, 0.7137, ..., 0.5020, 0.8431, 0.9922],
  [1.0000, 0.9765, 0.5882, ..., 0.5255, 0.8392, 1.0000],
  [1.0000, 1.0000, 0.9922, ..., 0.9843, 1.0000, 0.9922]],
 [[0.9843, 0.9843, 1.0000, ..., 0.9922, 1.0000, 1.0000],
  [0.9843, 0.9804, 1.0000, ..., 0.9922, 0.9922, 0.9961],
  [1.0000, 1.0000, 0.9059, ..., 0.8353, 0.9529, 0.9882],
  ...,
  [0.9647, 0.9647, 0.6627, ..., 0.4549, 0.8118, 0.9725],
  [0.9725, 0.9412, 0.5529, ..., 0.4941, 0.8196, 0.9843],
  [0.9922, 0.9843, 0.9765, ..., 0.9529, 0.9804, 0.9725]]]

Tensor Operations

val m = torch.rand(size=Seq(3,3))

m: Tensor[Float32] = tensor dtype=float32, shape=[3, 3], device=CPU
[[0.4963, 0.7682, 0.0885],
 [0.1320, 0.3074, 0.6341],
 [0.4901, 0.8964, 0.4556]]

val t = torch.arange(0, 3, dtype=float32)

t: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CPU
[0.0000, 1.0000, 2.0000]

m matmul t

res12: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CPU
[0.9452, 1.5756, 1.8077]

t + t

res13: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CPU
[0.0000, 2.0000, 4.0000]

t * 2 // Seq(0, 1, 2).map(x => x * 2)

res14: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CPU
[0.0000, 2.0000, 4.0000]

Using the GPU

import torch.Device.{CPU, CUDA}
val device = if torch.cuda.isAvailable then CUDA else CPU

val m = torch.rand(size=Seq(3,3), device=device)

m: Tensor[Float32] = tensor dtype=float32, shape=[3, 3], device=CUDA
[[0.3990, 0.5167, 0.0249],
 [0.9401, 0.9459, 0.7967],
 [0.4150, 0.8203, 0.2290]]

val t = torch.arange(0, 3, dtype=float32, device=device)

t: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CUDA
[0.0000, 1.0000, 2.0000]

m matmul t

res15: Tensor[Float32] = tensor dtype=float32, shape=[3], device=CUDA
[0.5665, 2.5393, 1.2783]

https://storch.dev/installation.html#enable-gpu-support

More Ops

https://storch.dev/api/torch.html#Grouped-members

Building models

The simplest model

Let’s learn the identity function!

def f(x: Int) = x

The simplest model

Let’s learn the identity function!

class Model:
  // our model weights (randomly initialized)
  val weights = torch.rand(Seq(1))
  // our model architecture
  def apply(x: Tensor[Int32]) = x * weights

val model = new Model()

model.weights

res20: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[0.1490]

The simplest model

val x = torch.Tensor(39)
val y = x // our "label" here is just the input

val z = model(x)

z: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[5.8126]

Let’s see how far we’re off

val loss = (z - y).abs

loss: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[33.1874]

Can we change the weights to make the loss go down?

Automatic Differentiation

We compute the derivative (gradient) of our loss function

class Model:
  // our model weights (randomly initialized)
  val weights = torch.rand(Seq(1))
  // our model architecture
  def apply(x: Tensor[Int32]) = x * weights

val model = new Model()

Automatic Differentiation

We compute the derivative (gradient) of our loss function

class Model:
  // our model weights (randomly initialized)
  // enable gradient tracking for our weights
  val weights = torch.rand(Seq(1), requiresGrad=true)
  // our model architecture
  def apply(x: Tensor[Int32]) = x * weights

val model = new Model()

Automatic Differentiation

val x = torch.Tensor(39)
val y = x // our "label" here is just the input

val z = model(x)

z: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[5.8126]

val loss = (z - y).abs

loss: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[33.1874]

Automatic Differentiation

Backpropagation (compute the gradients w.r.t. the weights)

loss.backward()
model.weights.grad

res62_1: Tensor[torch.Tensor[torch.Float32 | torch.Undefined]] = tensor dtype=float32, shape=[1], device=CPU
[-39.0000]

Update weights in the opposite direction of the gradient

model.weights

res63: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[0.1490]

noGrad {
  model.weights -= (model.weights.grad * 0.001f)
}

res64: Tensor[Float32] = tensor dtype=float32, shape=[1], device=CPU
[0.1880]

Gradient Descent

for step <- 1 to 20 do
  val x = torch.randint(low=0, high=100, size=Seq(1), dtype=int32) // input
  val y = x                   // expected output
  val z = model(x)            // predicted output
  val loss = (z - y).abs      // error/loss
  loss.backward()             // compute gradient
  noGrad {                    // disable gradient tracking locally
    // update weight based on gradient
    model.weights -= (model.weights.grad * 0.001f)
    model.weights.grad.zero()
  }

step	x	z	loss	old weight	gradient	new weight
1	44	08	36	0.1880	-44.00	0.2320

step	x	z	loss	old weight	gradient	new weight
2	39	09	30	0.2320	-39.00	0.2710

step	x	z	loss	old weight	gradient	new weight
3	33	09	24	0.2710	-33.00	0.3040

step	x	z	loss	old weight	gradient	new weight
4	60	18	42	0.3040	-60.00	0.3640

step	x	z	loss	old weight	gradient	new weight
5	63	23	40	0.3640	-63.00	0.4270

step	x	z	loss	old weight	gradient	new weight
6	79	34	45	0.4270	-79.00	0.5060

step	x	z	loss	old weight	gradient	new weight
7	27	14	13	0.5060	-27.00	0.5330

step	x	z	loss	old weight	gradient	new weight
8	03	02	01	0.5330	-3.00	0.5360

step	x	z	loss	old weight	gradient	new weight
9	97	52	45	0.5360	-97.00	0.6330

step	x	z	loss	old weight	gradient	new weight
10	83	53	30	0.6330	-83.00	0.7160

step	x	z	loss	old weight	gradient	new weight
11	01	01	00	0.7160	-1.00	0.7170

step	x	z	loss	old weight	gradient	new weight
12	66	47	19	0.7170	-66.00	0.7830

step	x	z	loss	old weight	gradient	new weight
13	56	44	12	0.7830	-56.00	0.8390

step	x	z	loss	old weight	gradient	new weight
14	99	83	16	0.8390	-99.00	0.9380

step	x	z	loss	old weight	gradient	new weight
15	78	73	05	0.9380	-78.00	1.0160

step	x	z	loss	old weight	gradient	new weight
16	76	77	01	1.0160	76.00	0.9400

step	x	z	loss	old weight	gradient	new weight
17	56	53	03	0.9400	-56.00	0.9960

step	x	z	loss	old weight	gradient	new weight
18	68	68	00	0.9960	-68.00	1.0640

step	x	z	loss	old weight	gradient	new weight
19	94	100	06	1.0640	94.00	0.9700

step	x	z	loss	old weight	gradient	new weight
20	33	32	01	0.9700	-33.00	1.0030

That’s how all AIs are trained!

The neural network API

class Model:
  val weights = torch.rand(Seq(1), requiresGrad=true)
  def apply(x: Tensor[Int32]) = x * weights

val model = new Model()

Let’s use the torch.nn API instead

import torch.nn

val model = nn.Linear(inFeatures=1, outFeatures=1) // Linear is a nn.Module

Scale up

val model = nn.Linear(inFeatures=12, outFeatures=1)

Scale up

val model = nn.Linear(inFeatures=12, outFeatures=8)

Scale up

val model = nn.Sequential( // Sequential is another nn.Module, a container
    nn.Linear(12, 8),
    nn.ReLU(),             // ReLU is a non-linear activation function
    nn.Linear(8, 2)
)

Scale up

val model = nn.Sequential( // Sequential is another nn.Module, a container
    nn.Linear(12, 8),
    nn.ReLU(),             // ReLU is a non-linear activation function
    nn.Linear(8, 8),
    nn.ReLU(),
    nn.Linear(8, 2)
)

Specialize

import torch.nn.functional as F
import torch.nn

class LeNet[D <: BFloat16 | Float32: Default] extends nn.Module:
  val conv1 = register(nn.Conv2d(1, 6, 5))
  val conv2 = register(nn.Conv2d(6, 16, 5))
  val fc1 = register(nn.Linear(16 * 4 * 4, 120))
  val fc2 = register(nn.Linear(120, 84))
  val fc3 = register(nn.Linear(84, 10))

  def apply(i: Tensor[D]): Tensor[D] =
    var x = F.maxPool2d(F.relu(conv1(i)), (2, 2))
    x = F.maxPool2d(F.relu(conv2(x)), 2)
    x = x.view(-1, 16 * 4 * 4)
    x = F.relu(fc1(x))
    x = F.relu(fc2(x))
    x = fc3(x)
    x

Scale up more

/** ResNet architecture implementations */
object resnet:
  /** 3x3 convolution with padding */
  def conv3x3[D <: BFloat16 | Float32 | Float64: Default](
      inPlanes: Int,
      outPlanes: Int,
      stride: Int = 1,
      groups: Int = 1,
      dilation: Int = 1
  ): Conv2d[D] =
    Conv2d[D](
      inPlanes,
      outPlanes,
      kernelSize = 3,
      stride = stride,
      padding = dilation,
      groups = groups,
      bias = false,
      dilation = dilation
    )

  /** 1x1 convolution */
  def conv1x1[D <: FloatNN: Default](inPlanes: Int, outPlanes: Int, stride: Int = 1): Conv2d[D] =
    Conv2d[D](inPlanes, outPlanes, kernelSize = 1, stride = stride, bias = false)

  sealed abstract class BlockBuilder:
    val expansion: Int
    def apply[D <: BFloat16 | Float32 | Float64: Default](
        inplanes: Int,
        planes: Int,
        stride: Int = 1,
        downsample: Option[TensorModule[D]] = None,
        groups: Int = 1,
        baseWidth: Int = 64,
        dilation: Int = 1,
        normLayer: (Int => HasWeight[D] & TensorModule[D])
    ): TensorModule[D] = this match
      case BasicBlock =>
        new BasicBlock(inplanes, planes, stride, downsample, groups, baseWidth, dilation, normLayer)
      case Bottleneck =>
        new Bottleneck(inplanes, planes, stride, downsample, groups, baseWidth, dilation, normLayer)

  object BasicBlock extends BlockBuilder:
    override val expansion: Int = 1

  object Bottleneck extends BlockBuilder:
    override val expansion: Int = 4

  class BasicBlock[D <: BFloat16 | Float32 | Float64: Default](
      inplanes: Int,
      planes: Int,
      stride: Int = 1,
      downsample: Option[TensorModule[D]] = None,
      groups: Int = 1,
      baseWidth: Int = 64,
      dilation: Int = 1,
      normLayer: => (Int => TensorModule[D])
  ) extends TensorModule[D] {
    import BasicBlock.expansion

    if groups != 1 || baseWidth != 64 then
      throw new IllegalArgumentException("BasicBlock only supports groups=1 and baseWidth=64")
    if dilation > 1 then throw new NotImplementedError("Dilation > 1 not supported in BasicBlock")
    // Both conv1 and downsample layers downsample the input when stride != 1
    val conv1 = register(conv3x3[D](inplanes, planes, stride))
    val bn1 = register(normLayer(planes))
    val relu = register(ReLU(inplace = true))
    val conv2 = register(conv3x3[D](planes, planes))
    val bn2 = register(normLayer(planes))
    downsample.foreach(downsample => register(downsample)(using Name("downsample")))

    def apply(x: Tensor[D]): Tensor[D] =
      var identity = x

      var out = conv1(x)
      out = bn1(out)
      out = relu(out)

      out = conv2(out)
      out = bn2(out)

      downsample.foreach { downsample =>
        identity = downsample(x)
      }

      out += identity
      out = relu(out)

      out
    override def toString(): String = getClass().getSimpleName()
  }

  /** Bottleneck in torchvision places the stride for downsampling at 3x3 convolution(self.conv2)
    * while original implementation places the stride at the first 1x1 convolution(self.conv1)
    * according to "Deep residual learning for image recognition"https://arxiv.org/abs/1512.03385.
    * This variant is also known as ResNet V1.5 and improves accuracy according to
    * https://ngc.nvidia.com/catalog/model-scripts/nvidia:resnet_50_v1_5_for_pytorch.
    */
  class Bottleneck[D <: BFloat16 | Float32 | Float64: Default](
      inplanes: Int,
      planes: Int,
      stride: Int = 1,
      downsample: Option[TensorModule[D]] = None,
      groups: Int = 1,
      baseWidth: Int = 64,
      dilation: Int = 1,
      normLayer: (Int => HasWeight[D] & TensorModule[D])
  ) extends TensorModule[D]:
    import Bottleneck.expansion

    val width = (planes * (baseWidth / 64.0)).toInt * groups
    // Both self.conv2 and self.downsample layers downsample the input when stride != 1
    val conv1 = register(conv1x1(inplanes, width))
    val bn1 = register(normLayer(width))
    val conv2 = register(conv3x3(width, width, stride, groups, dilation))
    val bn2 = register(normLayer(width))
    val conv3 = register(conv1x1(width, planes * expansion))
    val bn3 = register(normLayer(planes * expansion))
    val relu = register(ReLU(inplace = true))
    downsample.foreach(downsample => register(downsample)(using Name("downsample")))

    def apply(x: Tensor[D]): Tensor[D] =
      var identity = x

      var out = conv1(x)
      out = bn1(out)
      out = relu(out)

      out = conv2(out)
      out = bn2(out)
      out = relu(out)

      out = conv3(out)
      out = bn3(out)

      downsample.foreach { downsample =>
        identity = downsample(x)
      }

      out += identity
      out = relu(out)

      out
    override def toString(): String = getClass().getSimpleName()

  class ResNet[D <: BFloat16 | Float32 | Float64](
      block: BlockBuilder,
      layers: Seq[Int],
      numClasses: Int = 1000,
      zeroInitResidual: Boolean = false,
      groups: Int = 1,
      widthPerGroup: Int = 64,
      // each element in the tuple indicates if we should replace
      // the 2x2 stride with a dilated convolution instead
      replaceStrideWithDilation: (Boolean, Boolean, Boolean) = (false, false, false)
  )(using Default[D])(
      normLayer: (Int => HasWeight[D] & TensorModule[D]) =
        (numFeatures => BatchNorm2d[D](numFeatures))
  ) extends Module {
    var inplanes = 64
    var dilation = 1
    val baseWidth = widthPerGroup
    val conv1 = register(Conv2d(3, inplanes, kernelSize = 7, stride = 2, padding = 3, bias = false))
    val bn1 = register(normLayer(inplanes))
    val relu = register(ReLU(inplace = true))
    val maxpool = register(MaxPool2d(kernelSize = 3, stride = Some(2), padding = 1))
    val layer1 = register(makeLayer(block, 64, layers(0)))
    val layer2 = register(
      makeLayer(block, 128, layers(1), stride = 2, dilate = replaceStrideWithDilation(0))
    )
    val layer3 = register(
      makeLayer(block, 256, layers(2), stride = 2, dilate = replaceStrideWithDilation(1))
    )
    val layer4 = register(
      makeLayer(block, 512, layers(3), stride = 2, dilate = replaceStrideWithDilation(2))
    )
    val avgpool = register(AdaptiveAvgPool2d((1, 1)))
    val fc = register(Linear(512 * block.expansion, numClasses))

    for (m <- modules)
      m match
        case m: Conv2d[?] =>
          nn.init.kaimingNormal_(m.weight, mode = Mode.FanOut, nonlinearity = NonLinearity.ReLU)
        case m: BatchNorm2d[?] =>
          nn.init.constant_(m.weight, 1)
          nn.init.constant_(m.bias, 0)
        case m: nn.GroupNorm[?] =>
          nn.init.constant_(m.weight, 1)
          nn.init.constant_(m.bias, 0)
        case _ =>

    // Zero-initialize the last BN in each residual branch,
    // so that the residual branch starts with zeros, and each residual block behaves like an identity.
    // This improves the model by 0.2~0.3% according to https://arxiv.org/abs/1706.02677
    if zeroInitResidual then
      for (m <- modules)
        m match
          case m: Bottleneck[?] if m.bn3.weight.dtype != DType.undefined =>
            nn.init.constant_(m.bn3.weight, 0)
          case m: Bottleneck[?] if m.bn2.weight.dtype != DType.undefined =>
            nn.init.constant_(m.bn2.weight, 0)

    private def makeLayer(
        block: BlockBuilder,
        planes: Int,
        blocks: Int,
        stride: Int = 1,
        dilate: Boolean = false
    ): Sequential[D] = {
      var downsample: Option[TensorModule[D]] = None
      val previous_dilation = this.dilation
      var _stride: Int = stride
      if dilate then
        this.dilation *= stride
        _stride = 1
      if _stride != 1 || inplanes != planes * block.expansion then
        downsample = Some(
          Sequential(
            conv1x1(inplanes, planes * block.expansion, _stride),
            normLayer(planes * block.expansion)
          )
        )

      var layers = Vector[TensorModule[D]]()
      layers = layers :+ block(
        this.inplanes,
        planes,
        _stride,
        downsample,
        this.groups,
        this.baseWidth,
        previous_dilation,
        normLayer
      )

      inplanes = planes * block.expansion
      for (_ <- 1 until blocks)
        layers = layers :+
          block(
            this.inplanes,
            planes,
            groups = this.groups,
            baseWidth = this.baseWidth,
            dilation = this.dilation,
            normLayer = normLayer
          )

      Sequential(layers*)
    }

    private inline def forwardImpl(_x: Tensor[D]): Tensor[D] =
      var x = conv1(_x)
      x = bn1(x)
      x = relu(x)
      x = maxpool(x)

      x = layer1(x)
      x = layer2(x)
      x = layer3(x)
      x = layer4(x)

      x = avgpool(x)
      x = x.flatten(1)
      fc(x)

    def apply(x: Tensor[D]): Tensor[D] = forwardImpl(x)
  }

  private val weightsBaseUrl =
    "https://github.com/sbrunk/storch/releases/download/pretrained-weights/"

  case class Weights(
      url: String,
      transforms: Presets.ImageClassification
  )

  abstract class ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000): ResNet[D]
    val DEFAULT: Weights

  /** ResNet-18 from [Deep Residual Learning for Image
    * Recognition](https://arxiv.org/pdf/1512.03385.pdf).
    */
  object ResNet18 extends ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000) =
      ResNet[D](BasicBlock, Seq(2, 2, 2, 2), numClasses)()
    val IMAGENET1K_V1 = Weights(
      url = weightsBaseUrl + "resnet18-f37072fd.pth",
      Presets.ImageClassification(cropSize = 224)
    )
    val DEFAULT = IMAGENET1K_V1

  /** ResNet-34 from [Deep Residual Learning for Image
    * Recognition](https://arxiv.org/pdf/1512.03385.pdf).
    */
  object ResNet34 extends ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000) =
      ResNet[D](BasicBlock, Seq(3, 4, 6, 3), numClasses = numClasses)()
    val IMAGENET1K_V1 = Weights(
      url = weightsBaseUrl + "resnet34-b627a593.pth",
      transforms = Presets.ImageClassification(cropSize = 224)
    )
    val DEFAULT = IMAGENET1K_V1

  /** ResNet-50 from [Deep Residual Learning for Image
    * Recognition](https://arxiv.org/pdf/1512.03385.pdf)
    */
  object ResNet50 extends ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000) =
      ResNet(Bottleneck, Seq(3, 4, 6, 3), numClasses = numClasses)()
    val IMAGENET1K_V1 = Weights(
      url = weightsBaseUrl + "resnet50-0676ba61.pth",
      transforms = Presets.ImageClassification(cropSize = 224)
    )
    val IMAGENET1K_V2 = Weights(
      url = weightsBaseUrl + "resnet50-11ad3fa6.pth",
      transforms = Presets.ImageClassification(cropSize = 224, resizeSize = 232)
    )
    val DEFAULT = IMAGENET1K_V2

  /** ResNet-101 from [Deep Residual Learning for Image
    * Recognition](https://arxiv.org/pdf/1512.03385.pdf)
    */
  object ResNet101 extends ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000) =
      ResNet(Bottleneck, Seq(3, 4, 23, 3), numClasses = numClasses)()
    val IMAGENET1K_V1 = Weights(
      url = weightsBaseUrl + "resnet101-63fe2227.pth",
      transforms = Presets.ImageClassification(cropSize = 224)
    )
    val IMAGENET1K_V2 = Weights(
      url = weightsBaseUrl + "resnet101-cd907fc2.pth",
      transforms = Presets.ImageClassification(cropSize = 224, resizeSize = 232)
    )
    val DEFAULT = IMAGENET1K_V2

  /** ResNet-152 from [Deep Residual Learning for Image
    * Recognition](https://arxiv.org/pdf/1512.03385.pdf)
    */
  object ResNet152 extends ResNetFactory:
    def apply[D <: BFloat16 | Float32 | Float64: Default](numClasses: Int = 1000) =
      ResNet(Bottleneck, Seq(3, 8, 36, 3), numClasses = numClasses)()
    val IMAGENET1K_V1 = Weights(
      url = weightsBaseUrl + "resnet152-394f9c45.pth",
      transforms = Presets.ImageClassification(cropSize = 224)
    )
    val IMAGENET1K_V2 = Weights(
      url = weightsBaseUrl + "resnet152-f82ba261.pth",
      transforms = Presets.ImageClassification(cropSize = 224, resizeSize = 232)
    )
    val DEFAULT = IMAGENET1K_V2

  enum ResNetVariant(val factory: ResNetFactory):
    case ResNet18 extends ResNetVariant(resnet.this.ResNet18)
    case ResNet34 extends ResNetVariant(resnet.this.ResNet34)
    case ResNet50 extends ResNetVariant(resnet.this.ResNet50)
    case ResNet101 extends ResNetVariant(resnet.this.ResNet101)
    case ResNet152 extends ResNetVariant(resnet.this.ResNet152)

Training our image classifier

def dataLoader: Iterator[(Tensor[Float32], Tensor[Int64])] = ???
val model: ResNet[Float32] = ResNet34(numClasses = 2)
val optimizer = Adam(model.parameters, lr = 1e-5)
val lossFn = nn.loss.CrossEntropyLoss()

for epoch <- 1 to numEpochs do // loop through data
  for (input, label) <- dataLoader do // loop through batches
    optimizer.zeroGrad() // reset optimizer
    // ensure timely deallocation
    Using.resource(new PointerScope()) { _ =>
      val prediction = model(input)
      // compute loss (how good was the prediction)
      val loss = lossFn(prediction, label)
      loss.backward()  // compute the gradients of the loss
      optimizer.step() // update weights based on the gradients
    }

Training our image classifier

def dataLoader: Iterator[(Tensor[Float32], Tensor[Int64])] = ???
val model: ResNet[Float32] = ResNet34(numClasses = 2)
val optimizer = Adam(model.parameters, lr = 1e-5)
val lossFn = nn.loss.CrossEntropyLoss()

for epoch <- 1 to numEpochs do // loop through data
  for (input, label) <- dataLoader do // loop through batches
    optimizer.zeroGrad() // reset optimizer
    // ensure timely deallocation
    Using.resource(new PointerScope()) { _ =>
      val prediction = model(input)
      // compute loss (how good was the prediction)
      val loss = lossFn(prediction, label)
      loss.backward()  // compute the gradients of the loss
      optimizer.step() // update weights based on the gradients
    }

Training our image classifier

def dataLoader: Iterator[(Tensor[Float32], Tensor[Int64])] = ???
val model: ResNet[Float32] = ResNet34(numClasses = 2)
val optimizer = Adam(model.parameters, lr = 1e-5)
val lossFn = nn.loss.CrossEntropyLoss()

for epoch <- 1 to numEpochs do // loop through data
  for (input, label) <- dataLoader do // loop through batches
    optimizer.zeroGrad() // reset optimizer
    // ensure timely deallocation
    Using.resource(new PointerScope()) { _ =>
      val prediction = model(input)
      // compute loss (how good was the prediction)
      val loss = lossFn(prediction, label)
      loss.backward()  // compute the gradients of the loss
      optimizer.step() // update weights based on the gradients
    }

Storch under the hood

A lot of PyTorch is written in C++

Source: https://github.com/pytorch/pytorch/

LibTorch

How can we use this from Scala?

LibTorch is a large and complex C++ codebase
Do we have to write all that JNI code by hand? 🙀
JavaCPP to the rescue!

How can we use this from Scala?

🚀 The JavaCPP PyTorch bindings give us the full power of LibTorch from Java
😰 Writing C++ in Java syntax is not always pleasant though
😌 Storch provides an idiomatic Scala API on top

Safer Tensors with Types

PyTorch

torch.mean(torch.tensor(1))
# RuntimeError: mean(): could not infer output dtype.
# Input dtype must be either a floating point or complex dtype. Got: Long

Storch

def mean[D <: FloatNN | ComplexNN]( ... ) = ...

val t = torch.Tensor(1)

t: Tensor[Int32] = tensor dtype=int32, shape=[], device=CPU
1

torch.mean(t)
// error:
// torch.mean(t)
//            ^
// Found:    torch.Tensor[torch.Int32]
// Required: torch.Tensor[D]
// where:    D is a type variable with constraint <: torch.FloatNN | torch.ComplexNN

Safer Tensors with Types

DType.scala

/** Type of the output tensor based on PyTorch type promotion rules
  *
  * This is a type-level implementation of the PyTorch op data type promotion rules via match types.
  */
type Promoted[T <: DType, U <: DType] <: DType = (T, U) match
  case (T, T)                                    => T
  case (U, U)                                    => U
  // ...
  case (Int64, U)                                => U
  case (T, Int64)                                => T
  case (Float16, BFloat16) | (BFloat16, Float16) => Float32
  case (Float16, U)                              => U
  case (T, Float16)                              => T
  // ...

Tensor.scala

class Tensor[D <: DType]:
  def +[D2 <: DType](other: Tensor[D2]): Tensor[Promoted[D, D2]] = ???

Safer Tensors with Types

DType.scala

/** Promoted type for tensor division */
type Div[T <: DType, U <: DType] <: DType = (T, U) match
  case (BitwiseNN, BitwiseNN) => Float32
  case _                      => Promoted[T, U]

/** Promoted type for elementwise tensor sum */
type Sum[D <: DType] <: DType = D match
  case BitwiseNN => Int64
  case D         => D

Tensor.scala

class Tensor[D <: DType]:
  /** Divides each element of this tensor by the corresponding element of `other`. * */
  def /[D2 <: DType](other: Tensor[D2]): Tensor[Div[D, D2]] = div(other)

  /** Returns the sum of all elements of this tensor. */
  def sum: Tensor[Sum[D]] = Tensor(native.sum())

What’s next?

In progress
- Add more model architectures (transformers!)
- Improve op coverage
Ideas
- Improve performance (i.e. mixed precision training)
- Improve safety
  - Compile-time shapes & devices
  - Immutable Tensors
- Higher-level training abstractions

We want YOU!

🫵

https://storch.dev

Storch - GPU AcceleratedDeep Learning for Scala 3

AI is Mainstream

AI is software - just programmed differently

AI needs software

There’s a gap though

Storch - a Scala API for PyTorch

Let’s train a model!

Demo

Storch Features

Tensors

Creating Tensors

Creating Tensors

Tensor Operations

Using the GPU

More Ops

Building models

The simplest model

The simplest model

The simplest model

Automatic Differentiation

Automatic Differentiation

Automatic Differentiation

Automatic Differentiation

Gradient Descent

The neural network API

Scale up

Scale up

Scale up

Scale up

Specialize

Scale up more

Training our image classifier

Training our image classifier

Training our image classifier

Storch under the hood

A lot of PyTorch is written in C++

LibTorch

How can we use this from Scala?

How can we use this from Scala?

Safer Tensors with Types

Safer Tensors with Types

Safer Tensors with Types

What’s next?

We want YOU!

Thank you!

Storch - GPU Accelerated
Deep Learning for Scala 3
